EDGE Locate: High Precision GNSS Solution

Precise Centimeter-Level Positioning

Hardware platform providing high-precision GNSS for high-volume navigation and autonomous applications in an off-the-shelf, compact form factor

The TxWireless™ EDGE Locate system on module (SoM) is a high-precision GNSS platform for both large-scale and niche navigation and autonomous applications in an off-the-shelf, compact form factor.

The TxWireless EDGE Locate GNSS L1/L2/E5b combines the antenna, RF electronics, and receiver technology in a single package delivering reliable, high-accuracy positioning. Enterprises can quickly and effectively build IoT devices with cm-level positioning technology, without having to invest in costly and lengthy RF design, integration, and testing processes. Integrating the antenna and the GNSS receiver into one package eliminates the need for long RF cabling, allowing simple UART or USB cables to be used for interfacing to the device.

Precise Centimeter-Level Positioning

Hardware platform providing high-precision GNSS for high-volume navigation and autonomous applications in an off-the-shelf, compact form factor

The TxWireless™ EDGE Locate system on module (SoM) is a high-precision GNSS platform for both large-scale and niche navigation and autonomous applications in an off-the-shelf, compact form factor.

Key Benefits

Hardware Specs

Features

Hardware Specs

Models Name	EL20A
GNSS Module	u-blox ZED-F9P
Antenna	Taoglas AGPSF.36G Embedded Active Dual-band GNSS L1/L2 Stacked Patch Antenna
GNSS Constellations	GPS/QZSS (L1/L2) + GLONASS (G1/G3) + GALILEO (E1/E5b + BeiDou(B1/B2b)
Number of Channels	184
TTFF	<60s / Warm start <10s
Interface	SPI/UART via PMOD header Geofence output pin Power control pin (default On)
Operation Temperature	GPS/QZSS (L1/L2) + GLONASS (G1/G3) + GALILEO (E1/E5b + BeiDou(B1/B2b)
Weight	40g
Input Voltage	5.0v
Position accuracy	Up to 0.01m + 1 ppm CEP (RTK) Up to 0.05m (without RTK)
Nav update rate	Up to 20
Hz Acquisition Sensitivity	-129dBm
Tracking Sensitivity	-147dBm

Features

EDGE Locate Features
High-end RTK receiver.
Integrated and validated multi-band antenna.
Integrated u-blox ZedF9P multi-band GNSS Receiver.
Concurrent reception of GPS, GLONASS, Galileo, and BeiDou.
Advanced anti-spoofing and anti-jamming.
PMOD compatible and easy to integrate into third-party hardware.
Pre-certified and validated electronics.
Easy integration with EDGE Connect for full cellular connectivity.
REACH & RoHS Compliant.

Applications

In the field with the EDGE Locate

Surveying and Mapping

Provides accurate geospatial data, enabling precise land measurements, cartography, and infrastructure planning.

Professional Sports

Track movements and performance metrics, offering valuable insights on their performance.

UAVs

Enables precise and autonomous navigation for drones, ensuring accurate positioning, tracking, and flight control.

Precision Agriculture

Enables precision farming by optimizing resource usage based on geospatial data and providing live telemetry data via cellular networks.

Robotic Guidance

Provides accurate positional information, enabling robots to navigate, perform tasks, and interact with their environments with precision and efficiency.

Micro Mobility

Provides accurate location data for e-scooters, e-bikes, and other small electric vehicles, enabling efficient route planning, rider safety, and fleet management.

Built-In Comprehensive Connectivity

TxWireless EDGE Locate combines GNSS and correction services for a turnkey, off-the-shelf IoT hardware and software platform.

GNSS systems like GPS, GLONASS, and Galileo are essential for IoT applications, providing highly accurate location data that’s crucial for asset tracking, fleet management, logistics, and safety. As a result, GNSS enhances operational efficiency and decision-making across a wide variety of industries and applications.

GNSS correction services provide crucial adjustments to compensate for factors like atmospheric interference and satellite clock inaccuracies. Whether real-time or post-processed, GNSS correction services use ground-based reference stations to ensure precise positioning with sub-meter to centimeter-level accuracy, making them indispensable for applications like autonomous vehicles, precision agriculture, and surveying.

Capabilities

The TxWireless design and manufacturing teams can accelerate your enterprise’s digitization journey. Drawing upon decades of expertise in connected devices, our team adheres to a well-defined integration process. Our diverse design teams skills encompass industrial, electrical, mechanical, firmware, device software, solution architecture, and testing. We can serve as your co-pilot to accelerate your connected device strategy.

Resources

Datasheets
View the detailed technical specifications for this device

Application Notes
View the complete application notes for this device.

User Guide
View the comprehensive user guide for this device.

Quick Start Guide
View the quick start guide for this device.
